Model | XY-130 |
Drilling depth | 10-130m |
Max open hole caliber | 260mm |
End hole caliber | 75mm |
Drill rod caliber | 50mm |
Drilling angle | 90°~75° |
Drill weight (without power) | 510kg |
Power | Diesel engine18HP |
Dimension | 2.4*0.8*1.4 |
spindle speed | 142,285,570r/min |
Spindle stroke | 450mm |
Max.lifting capacity | 2000kg |
Single line lifting speed | 0.41,0.82,1.64m/s |
Wirerope caliber | 13mm |
Wirerope length | 27m |
Type | Horizontal single-urn twin-action |
Displacement | 95/77L/min |
Maximum pressure | 1.2Mpa |
Work pressure | 0.7Mpa |
Inlet pipe caliber | 51mm |
Outlet pipe caliber | 32mm |
Triangle conveyer belt | B1575mm |
MOQ | 1Set |
Price(usd) | 6000 |
Contact Person : | Lena |
---|
