Diesel Engine | Model | Cummins 6BTA5.9-C180 (turbocharged and charge water cooled) |
Displacement | 5.9L (1.56 US Gallons) | |
Power | 132Kw (180HP) | |
Rated RPM(Factory setting) | 2200rpm | |
Drilling Capacity | BQ | 1000m(3280feet) |
NQ | 700m(2296 feet) | |
HQ | 500m(1640 feet) | |
PQ | 300m(984 feet) | |
Drill Head | RPM | Four Shifts/ Stepless Change 0-1100 RPM |
Max. Torque | 4200 N·m(3108lbf·ft) | |
Hold Diameter | 98mm(3.85 inch) | |
Max. Lifting capacity of Spindle | 150 kN(33720 lbf) | |
Max. Feeding Power | 60 kN(13480 lbf) | |
Primary Pump | Hydraulic pump Axial Piston variable displacement Triplex pump for driving of rotator, winch mud pump & leveling jacks. With load sensing system. | 1st Pump：140LPM at 30MPa 2nd Pump：120LPM at 25MPa 3rd Pump： 50 LPM at 20MPa |
Hydraulic Tank | Capacity | 310 L (82 US Gallons) |
Capacity of Main Hoist | Hoisting force (single wire) | 57kN(12814 lbf) (bare drum) |
Hoisting Speed (single wire) | 38-40m/min (bare drum) | |
Steel Wire Diameter | 16 mm(0.62 inch) | |
Steel Wire Length | 50 m(164 feet) | |
Capacity of Wireline Hoist | Hoisting Force (single wire) | 1200 Kg(2646 lb) (bare drum) |
Hoisting Speed (single wire) | 130-400m/min (bare drum) | |
Steel Wire Diameter | 6 mm(0.23 inch) | |
Steel Wire Length | 1000 m(3280 feet) | |
Mast | Mast Height | 9 m(29.52 feet) |
Mast Adjusting Angle | 0°—90° | |
Drilling Angle | 45º off horizontal to 90ºvertical down | |
Feed Pull | 15000kg(33075 lb) | |
Feed Thrust | 6000kg(13230 lb) | |
Rod Pull | 3m or 6m(9.84feet or 19.68feet) | |
Feeding Stroke | 3500 mm(11.48ft) | |
Slippage Stroke | 1100 mm(3.6ft) | |
Mud Pump | Type | Reciprocating pump Triplex Plunger |
Model | BW160/10 | |
Foot Clamp | Clamping Scope | 55.5-110 mm(2.19-4.33 inch) through hole Ф154mm(6.06 inch) |
Others | Weight (platform type) | 9300 Kg(20506 lb) |
Dimensions (L×W×H) | 5100×2200×2450mm (16.73×7.21×8.03ft) | |
Transport Way | Crawler |
